The E-Vertic X-Type is an aluminum hardtail ready to experience the emotions of an excursion into nature. Reactive, powerful and with a geometry that ensures stability and agility, it was created to venture onto the most panoramic trails.

Bosch Performance Line engine and 625Wh battery, a front suspended with 29-inch wheels that does not fear any climb and guarantees over 100km of autonomy on flat terrain.

For users with an indicative height between 185/195cm.

Technical Specifications

Frame Kit
e-VERTIC X-Type ALU size: 43, 48, 53 - Quick release dropouts 9x135 mm - 180 post mount disc brake - 120 mm front travel - Internal cable routing on the fork - Compatible with 625Wh (purchasing specific adapter and battery separately)
Suntour XCR34-AIR-Boost LOR DS 15QLC32-110 29" fork, 120 mm travel, 1.5" tapered HT, 15QLC32-110 thru axle, 180 mm minimum rotor, 203 mm maximum rotor, LOR type shock absorber, 34 mm stanchions, air
Acros AZF-575 1.8" top / 1.5" headset - internal cable routing

Drive Unit
Bosch Performance Line CX, 250W, 85Nm, Purion display
Battery Bosch PowerTube 625Wh integrated battery

Transmission
Shifter Shimano, SL-M4100-R, DEORE, 10 speed
Rear derailleur Shimano Deore RD-M4120 10 speed (11 speed compatible)
Crankset FSA CK-320/IS/Gen4 FSA E-Bike Diecast ISIS / 165mm / Die-cast aluminum
Chain KMC e10S NPBK

Braking system
Brakes Promax DSK-925
Rotors Promax DSK-925, 180mm, center lock

Wheels
Rims Velomann E-Sport Tubeless Ready 29", 622x25, 32 hole
Rear hub Formula CL-1422 - 145 mm axle
Front hub Formula CL-811 for central fixing, 32h, 15x110mm TA
TiresChaoyang Phantom dry 29x2.3, 60tpi

Handlebar
Stem Velomann Viper0, 60mm, 31.8mm, 1"1/8
Bar Velomann, width 740mm, diam 31.8mm, rise 15mm, backsweep 9°
Tape/grips T-One Rock T-GP34 single grip, TPR, 130mm, plastic inner body, aluminum clamp

Saddle
Seatpost Velomann, diam.31.6mm, 0mm seatback, 300mm size 43 350mm size 48 400mm size 53
Saddle Velomann Gnd Full-fit Start Up, carbon steel rail, 262x145

Geometry
